CGEM II 925 SCHMIDT-CASSEGRAIN TELESCOPES

Celestron

$3,999.00
(No reviews yet) Write a Review
SKU:
CEL12011
Adding to cart… The item has been added

SUMMARY:

The CGEM II 925 Schmidt-Cassegrain Telescope features Celestron’s premium StarBright XLT coated optics and the newly redesigned CGEM II computerized equatorial mount. The CGEM II 925 offers the middle ground for those looking to combine portability with high resolution. This telescope is especially at home as a solid platform for long exposure photography with optional CCD cameras or photographic equipment. With over 925 inches of aperture and our premium StarBright XLT coatings, the CGEM II 925 gives you over 1000 times the light gathering power than the unaided eye.

A fresh update to the venerable CGEM mount, the CGEM II has a fresh, attractive, bold appearance and is capable of carrying Celestron’s higher-end SCT optical tubes (up to 11") securely and vibration free, which is ideal for both imaging and visual observing. Capable of holding 40 lbs. of payload and slewing at 5° per second, you will be able to instantly point to any of the celestial objects in the database.



ERGONOMIC DESIGN

CGEM II was designed to be ergonomically friendly with large Altitude and Azimuth adjustment knobs for quick and easy polar alignment adjustment. The internal RA and DEC motor wiring provides a clean look and an easy and trouble free set up.



INNOVATION

The CGEM II series features Celestron’s innovative Polar alignment procedure called All-Star™. All-Star allows users to choose any bright star, while the software calculates and assists with polar alignment. Another great feature of the CGEM II sure to please astroimagers, is the Permanent Periodic Error Correction (PEC) which will allow users to train out the worm gears periodic errors, while the mount retains the PEC recordings.



PERFORMANCE

For objects near the Meridian (imaginary line passing from North to South), the CGEM II will track well past the Meridian for uninterrupted imaging through the most ideal part of the sky. The CGEM II mount has a robust database with over 40,000 objects, 100 user defined programmable objects and enhanced information on over 200 objects. Celestron's CGEM II mount is the perfect fit between the Advanced Series and CGE Series. Offering the portability of the Advanced Series and the precision of the CGE.

OPTICAL TUBE INFO: Optical Design Schmidt-Cassegrain Aperture (mm) 234.95 mm (9.25") Focal Length 2350 mm (93") Focal Ratio 10 Focal Length of Eyepiece 1 (mm) 25 mm (0.98") Magnification of Eyepiece 1 94x Finderscpoe 6x30 Star Diagonal 1.25 Optical Tube Aluminum Highest Useful Magnification 555x Lowest Useful Magnification 34x Limiting Stellar Magnitude 14.4 Resolution (Rayleigh) 0.59 arc seconds Resolution (Dawes) 0.49 arc seconds Light Gathering Power (Compared to human eye) 1127x Secondary Mirror Obstruction 85 mm (3.35") Secondary Mirror Obstruction by Diameter 36% Secondary Mirror Obstruction by Area 13% Optical Coatings StarBright XLT Optical Tube Length 559 mm (22") Optical Tube Weight 20 lbs (9.07 kg) Dovetail Compatibility CGE Mount MOUNT INFO: Mount Type German Equatorial Mount Tripod 2" Steel tripod with graduated markings on lower section Dovetail Mount Directly connects to both CG-5 & CGE dovetail bars Payload Capacity 40 lbs Latitude Range 15° - 70° Power Requirements 12 VDC, 3.2 amps Ports 1x Hand control port, 1x Auxiliary Port, 1x Auto guider port, 1 USB 2.0 port (on hand control) Motor Drive Low cog DC servo motors Slew Speeds 9 slew speeds Tracking Rates Sidereal, Solar and Lunar Tracking Modes EQ North and EQ South Alignment Procedures AutoAlign, 2-Star Align, Quick Align, 1-Star Align, Last Alignment, Solar System Align Computerized Hand Control Double line, 16 character Liquid Crystal Display; 19 fiber optic backlit LED buttons, USB 2.0 port for PC connection Database 40,000+ objects, 100 user defined programmable objects. Enhanced information on over 200 objects Mount Weight 40 lbs Tripod Weight 20 lbs Weight of Counterweight 1x 17 lbs, 1x 11 lbs Counterweights Total Weight of Mount Kit 77 lbs
